Engine Mfg. Shangdong
Huasheng
|
Single cylinder, 4 stoke , air
cooled
|
Displacement
|
49cc
|
Brake
|
Rear
disc
|
Ignition
|
CDI
|
Starting
|
Electric
pull start
|
Tranmission
|
Chain
|
Front
suspension
|
Independent dual A-Arm
|
Suspension
|
Swing arm
|
Front
tire
|
At 12.5*4.1-6
|
Rear tire
|
at 13*4.5-6
|
Dimention
|
1450*940*1030 mm
|
Wheel
base 1050 mm
|
Turn
radius
|
1500 mm
|
Ground
clear
|
100 mm
|
Dry weight
|
55 kgs
|
Max speed
|
25 km/h
|
Gross
weight
|
115kg
|
Load
|
2 riders or 60kg
|
Fuel tank
|
4 L
|
Battery
|
12V 6.5AH
|
Head light
|
2*12V15W
|
Tail
light
|
12V 21W / 5W
|
|
|
